Product Name:Triangular Custom Ceramic Linings

  • Product Category:
    • Product Details:
      Cutting tiles is much different from standard wear ceramic liner tile.cutting tiles can minimized the gaps and ensure a very tight fit with minimum space at the joints
    • E-Mail:

    Customized Triangular Ceramic Linings

    Triangular Ceramic Linings -cutting tiles can minimized the gaps and ensure a very tight fit with minimum space at the joints


    Product Description :

    Cutting tiles is much different from standard wear ceramic liner tile . Which is cutted into special shape tile from standard tiles . Cutting tiles is most perfect for complex equipment components. If standard alumina ceramic lining lined complex components, it will results in gaps between the tiles , and the epoxies used to bond the tiles wear rapidly , as wear progresses , the tile surface becomes increasingly uneven, resulting in accelerated wear. Chemshun cutting tiles can minimized the gaps and ensure a very tight fit with minimum space at the joints

    Products Advantages :

    -- Long lifetime and maintenance free operation

    -- No operation interruption or production losses

    -- Maximum efficiency of separation

    -- superiority of cyclone ceramic tile designed confirmed by computer

    Chemical Composition:

    Al2O3SiO2CaOMgONa2O
    92~93%3~6%1~1.6%0.2~0.8%0.1%

    Physical Properties:

     Specific gravity (g/cc)>3.60
     Apparent porosity (%)0
     Flexural Strength (20℃, Mpa)280
     Compressive strength (20℃, Mpa)850
     Rockwell hardness (HRA)80
     Vickers hardness (hv)1050
     Moh’s hardness (scale)≥9
     Thermal Expansion (20-800℃, x10-6/℃)8
     Crystal Size (μm)1.3~3.0

    Package Pictures :

    Customized triangular ceramic linings package

    Product Technical Data (1:wear resistant ceramic)

    Product PDF Brochure Download
